Ürün ayrıntıları:
Ödeme & teslimat koşulları:
|
| Vurgulamak: | gravity feed solenoid valve,electric air solenoid valve |
||
|---|---|---|---|
Uygulanabilir aralık (Pa) elektro manyetik vakum gazı solenoid valfı
3. Detaylı Bilgi
| model | Liman | ağız | Özgeçmiş | Min. Basınç | Maks. Basınç | Gövde Malzemesi | Conta Malzemesi | bobin | |
| AC (22VA) | DC (17W) | ||||||||
| NLHN31161XXX | 1/8" | 1.6 | 0.11 | 0.0Mpa | 1.6Mpa | 1.6Mpa | Pirinç SS304 SS316 | NBR EPDM Viton (FKM) | S91B |
| NLHN31251XXX | 1/8" | 2.5 | 0.18 | 0.0Mpa | 1.2Mpa | 1.2Mpa | S91B | ||
| NLHN31301XXX | 1/8" | 3.0 | 0.3 | 0.0Mpa | 1.0Mpa | 1.0Mpa | S91B | ||
| NLHN31252XXX | 1/4" | 2.5 | 0.18 | 0.0Mpa | 1.2Mpa | 1.2Mpa | S91B | ||
| NLHN31302XXX | 1/4" | 3.0 | 0.3 | 0.0Mpa | 1.0Mpa | 1.0Mpa | S91B | ||
| NLHN31352XXX | 1/4" | 3.5 | 0.34 | 0.0Mpa | 0.8Mpa | 0.8Mpa | S91B | ||
| NLHN31402XXX | 1/4" | 4,0 | 0.5 | 0.0Mpa | 0.6MPa | 0.6MPa | S91B | ||
| NLHN31452XXX | 1/4" | 4.5 | 0.61 | 0.0Mpa | 0.4MPa | 0.4MPa | S91B | ||
| NLHN31403XXX | 3/8" | 4,0 | 0.5 | 0.0Mpa | 0.6MPa | 0.6MPa | S91B | ||
| NLHN31453XXX | 3/8" | 4.5 | 0.61 | 0.0Mpa | 0.4MPa | 0.4MPa | S91B | ||
| NLHN31503XXX | 3/8" | 5.0 | 0,71 | 0.0Mpa | 0.3MPa | 0.3MPa | S91B | ||
| NLHN31603XXX | 3/8" | 6 | 0.8 | 0.0Mpa | 0.3MPa | 0.3MPa | S91B | ||
| model | Liman | ağız | Özgeçmiş | Min. Basınç | Maks. Basınç | Gövde Malzemesi | Conta Malzemesi | bobin | |
| AC (24VA) | DC (18W) | ||||||||
| NLHN41161XXX | 1/8" | 1.6 | 0.11 | 0.0Mpa | 1.6Mpa | 1.6Mpa | Pirinç SS304 SS316 | NBR EPDM Viton (FKM) | S21B |
| NLHN41251XXX | 1/8" | 2.5 | 0.18 | 0.0Mpa | 1.4Mpa | 1.4Mpa | S21B | ||
| NLHN41301XXX | 1/8" | 3.0 | 0.3 | 0.0Mpa | 1.2Mpa | 1.2Mpa | S21B | ||
| NLHN41252XXX | 1/4" | 2.5 | 0.18 | 0.0Mpa | 1.4Mpa | 1.4Mpa | S21B | ||
| NLHN41302XXX | 1/4" | 3.0 | 0.3 | 0.0Mpa | 1.2Mpa | 1.2Mpa | S21B | ||
| NLHN41352XXX | 1/4" | 3.5 | 0.34 | 0.0Mpa | 0.9Mpa | 0.9Mpa | S21B | ||
| NLHN41402XXX | 1/4" | 4,0 | 0.5 | 0.0Mpa | 0.7Mpa | 0.7Mpa | S21B | ||
| NLHN41452XXX | 1/4" | 4.5 | 0.61 | 0.0Mpa | 0.5Mpa | 0.5Mpa | S21B | ||
| NLHN41403XXX | 3/8" | 4,0 | 0.5 | 0.0Mpa | 0.7Mpa | 0.7Mpa | S21B | ||
| NLHN41453XXX | 3/8" | 4.5 | 0.61 | 0.0Mpa | 0.5Mpa | 0.5Mpa | S21B | ||
| NLHN41503XXX | 3/8" | 5.0 | 0,71 | 0.0Mpa | 0.5Mpa | 0.5Mpa | S21B | ||
| NLHN41603XXX | 3/8" | 6 | 0.8 | 0.0Mpa | 0.4MPa | 0.4MPa | S21B | ||
| model | Liman | ağız | Özgeçmiş | Min. Basınç | Maks. Basınç | Gövde Malzemesi | Conta Malzemesi | bobin | |
| AC (22VA) | DC (17W) | ||||||||
| NLHN32161XXX | 1/8" | 1.6 | 0.11 | 0.0Mpa | 1.6Mpa | 1.6Mpa | Pirinç SS304 SS316 | NBR EPDM Viton (FKM) | S91B |
| NLHN32251XXX | 1/8" | 2.5 | 0.18 | 0.0Mpa | 1.2Mpa | 1.2Mpa | S91B | ||
| NLHN32301XXX | 1/8" | 3.0 | 0.3 | 0.0Mpa | 1.0Mpa | 1.0Mpa | S91B | ||
| NLHN32252XXX | 1/4" | 2.5 | 0.18 | 0.0Mpa | 1.2Mpa | 1.2Mpa | S91B | ||
| NLHN32302XXX | 1/4" | 3.0 | 0.3 | 0.0Mpa | 1.0Mpa | 1.0Mpa | S91B | ||
| NLHN32352XXX | 1/4" | 3.5 | 0.34 | 0.0Mpa | 0.8Mpa | 0.8Mpa | S91B | ||
| NLHN32402XXX | 1/4" | 4,0 | 0.5 | 0.0Mpa | 0.6MPa | 0.6MPa | S91B | ||
| NLHN32452XXX | 1/4" | 4.5 | 0.61 | 0.0Mpa | 0.4MPa | 0.4MPa | S91B | ||
| NLHN32403XXX | 3/8" | 4,0 | 0.5 | 0.0Mpa | 0.6MPa | 0.6MPa | S91B | ||
| NLHN32453XXX | 3/8" | 4.5 | 0.61 | 0.0Mpa | 0.4MPa | 0.4MPa | S91B | ||
| NLHN32503XXX | 3/8" | 5.0 | 0,71 | 0.0Mpa | 0.3MPa | 0.3MPa | S91B | ||
| NLHN32603XXX | 3/8" | 6 | 0.8 | 0.0Mpa | 0.3MPa | 0.3MPa | S91B | ||
| NLHN32803XXX | 3/8" | 8 | 1.25 | 0.0Mpa | 0.1Mpa | 0.1Mpa | S91B | ||
| NLHN32114XXX | 1/2" | 10 | 1,72 | 0.0Mpa | 0.1Mpa | 0.1Mpa | S91B | ||
